Thermostat

This switch is designed for reliable performance in various electrical and mechanical systems. It is available in normally open (NO) and normally closed (NC) configurations, with SPST and SPDT options to suit different circuit requirements. Capable of handling up to 45A at 240V, it ensures dependable operation in demanding environments. With flexible cover types and mounting angles, it can be customized to meet specific installation needs, making it suitable for applications such as air compressors, heating and ventilation systems, vending machines, clothes dryers, and heating equipment.

Download Brochure Enquire on WhatsApp

RV-EC Series

A. RV-ECWP Series (Ordinary Type)

Pressure-type thermostat for window air conditioners and split air conditioners.

B. RV-ECWY-S Series (High Temperature Type)

Manual reset thermal cut-off for electric water heaters and other electric heating appliances.

C. RV-ECWY-F Series (High Temperature Type)

Liquid expansion type thermostat for electric heating appliances including electric water heaters, washing machines, electric ovens, deep fryers, and hot water dispensers.

D. RV-ECWDF Series (Constant Temperature & Repositioning Type)

Pressure thermostat for refrigerator and freezer applications.

D Series

Contact Capacity: 16A/400V
Temperature range: 75-130C
Application: Overheat protection for water heaters,boilers, and related equipmentHousing temperature rating: T85 Capillary length: 300-1500 mm

A 2000 Series / F 2000 Series

Contact Capacity: C-116A C-2 4A/250V
Temperature range: -35-35°℃ /0-40℃
Application: Cold storage and refrigerated chambers
Capillary length: 150-3000 mm
Switching differential: 1-3℃

Features

Available in normally open (NO) and normally closed (NC) types
Available in single pole single throw (SPST) and single pole double throw (SPDT) types
Maximum load current: 45A at 240V
Different cover types and mounting angles can be provided according to customer requirements
