The RVP-DP-HB Permanent Magnet Centrifugal Pump is designed for efficient and reliable water supply in commercial and domestic applications. It is ideal for commercial water boosting, domestic groundwater extraction, and household water supply systems. With advanced permanent magnet technology, the pump ensures stable performance, energy efficiency, and dependable operation under various operating conditions.
1.Commercial water boosting
2.Domestic groundwater extraction
3.Domestic water supply boosting
Operation Condition
| Model | RVP-DP-HB03-30EC Pro | RVP-DP-HB03-30EC | RVP-DP-HB06-22EC |
|---|---|---|---|
| Voltage | 220V/50Hz | 220V/50Hz | AC 220V/50Hz |
| Liquid PH | 6.5~8.5 | 6.5 ~ 8.5 | 6.5~8.5 |
| Maximum particle size | 0.1mm | 0.1mm | 0.1mm |
| Medium temperature | 0°C ~ 50°C | 0°C ~ 50°C | 0°C ~ 90°C |
| Ambient temperature | 0°C ~ 55°C | 0°C ~ 55°C | 0°C ~ 40°C |
| Voltage fluctuation range | ±10% | ±10% | ±10% |
Technical Parameters
| Model | Max. Flow | Max. Head | Rated Flow | Rated Head | Max. Power | Rated Voltage | Max. RPM | Inlet & Outlet Size |
|---|---|---|---|---|---|---|---|---|
| (m³/h) | (m) | (m³/h) | (m) | (W) | (V) | (r/min) | (Internal Thread) | |
| RVP-DP-HB03-30EC Pro | 5.5 | 45 | 3 | 30 | 600 | 220 | 5000 | G1" |
| RVP-DP-HB03-30EC | 5.5 | 45 | 3 | 30 | 600 | 220 | 5000 | G1" |
| RVP-DP-HB06-22EC | 8.5 | 28 | 6 | 22 | 700 | 220 | 5000 | G1" |
