The RVP-DP-PS Household Pump is designed for efficient and reliable water flow in heating systems. It features a compact and lightweight design, low noise operation, and a rust-resistant coated body for long-lasting durability. Equipped with a high-quality mechanical seal, it ensures stable performance and easy maintenance, making it suitable for residential and commercial hot water circulation applications.
1.The pump body is coated with a special coating, Rust resistance
2.Low noise and high head
3.Compact structure and light appearance
4.High quality mechanical seal, reliable and easy to maintain
5.Painted appearance, simple and elegant
Technical Parameters
| Power supply | 1~220V/50Hz, 3~380V/50Hz |
| Motor protection | Single-phase motor with thermal protection, three-phase motor without |
| IP protection | IP44 |
| Insulation | F |
| (RH) Humidity | ≤95% |
| System pressure | 0.4Mpa.0.5Mpa |
| Certificate | CE |
| Ambient temperature | 0~40°C |
| Liquid temperature | 0~90°C (clean water) |
| Model | a | b | c | d | e | f | g | h | i |
|---|---|---|---|---|---|---|---|---|---|
| RVP-DP-PS-400 | 283 | 243 | 219 | 94 | 124 | 172 | 172 | 172 | 172 |
| RVP-DP-PS-600 | 306 | 258 | 230 | 98 | 142 | 180 | 180 | 180 | 180 |
| RVP-DP-PS-750 | 322 | 269 | 233 | 98 | 142 | 180 | 180 | 180 | 180 |
| RVP-DP-PS-751 | 315 | 269 | 234 | 98 | 142 | 180 | 180 | 180 | 180 |
| RVP-DP-PS-1100 | 384.5 | 345 | 275 | 126 | 240 | 294.5 | 219 | 85 |
